Van Nicholas Rowtag Size Chart
| Size |
XS |
S |
M |
L |
XL |
| Effective Frame Size |
480 |
510 |
540 |
570 |
600 |
| Seat Tube Length (CTT) |
480 |
510 |
540 |
570 |
600 |
| Seat Tube Length (CTC) |
430 |
460 |
490 |
520 |
550 |
| Effective Top Tube (Eff TT) |
525 |
540 |
550 |
570 |
585 |
| Actual Top Tube (Act TT) |
506 |
522 |
533 |
552 |
567 |
| Head Tube Angle (HA) |
70 |
70.5 |
70.5 |
70.5 |
71 |
| Seat Tube Angle (SA) |
74 |
74 |
73 |
73 |
73 |
| Head Tube Length (HT) |
120 |
135 |
160 |
185 |
210 |
| Wheel Base (WB) |
1027 |
1038 |
1050 |
1061 |
1071 |
| Front Centre (FC) |
597 |
608 |
619 |
630 |
641 |
| Bottom Bracket Drop (BB Dr.) |
70 |
70 |
70 |
70 |
70 |
| Chain Stay Length (CS) |
440 |
440 |
440 |
440 |
440 |
| Fork Rake (Rake) |
50 |
50 |
50 |
50 |
50 |
| Weight (Lbs) |
4.29 |
4.42 |
4.56 |
4.69 |
4.83 |
| Weight (Kgs) |
1.95 |
2.01 |
2.07 |
2.13 |
2.19 |
| Stack |
543 |
559 |
582 |
608 |
631 |
| Reach |
367 |
378 |
381 |
384 |
391 |
| Standover |
768 |
790 |
816 |
841 |
868 |
